VP3520
VP3520 Seamless Presentation Matrix Switch ความละเอียด True 4K รองรับการควบคุมอุปกรณ์ด้วย IR, RS-232, PJLink และ relay port
กรุณาสอบถามทาง Line @macrocare
สินค้ามีจำนวนจำกัด
Availability date:
5 x 2 True 4K Seamless Presentation Matrix Switch with Control
VP3520 Seamless Presentation Matrix Switch ความละเอียด True 4K รองรับการควบคุมอุปกรณ์ด้วย IR, RS-232, PJLink และ relay port
ผู้รับ: :
* ฟิลด์ที่จำเป็น
หรือ ยกเลิก
Video Input | |
Interfaces | 3 x HDMI Type A female (Black) 2 x HDBaseT (RJ-45) Female (Silver) with PoH |
Max. Distance | HDMI: 4K@60Hz (4:4:4) at 5m; 4K@30Hz at 10m; 1080p@60Hz at 15m HDBaseT: 4K@30Hz at 35m (Cat 5e/6) / 40m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@60Hz at 60m (Cat 5e/6) / 70m (Cat 6a/ATEN 2L-2910 Cat6) |
Video Output | |
Interfaces | 1 x HDMI Type A female (Black) 1 x HDBaseT (RJ-45) Female (Silver) with PoH |
Max. Distance | HDMI: 4K@60Hz (4:4:4) at 5m; 4K@30Hz at 10m; 1080p@60Hz at 15m HDBaseT: 4K@30Hz at 35m (Cat 5e/6) / 40m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@60Hz at 60m (Cat 5e/6) / 70m (Cat 6a/ATEN 2L-2910 Cat6) |
Video | |
Max. Resolution | HDMI: Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) HDBaseT: Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0) ; Up to 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
Compliance | HDMI; 4K HDR HDCP 2.2 Compatible; Consumer Electronics Control (CEC) |
Audio | |
Output | Line Out (Unbalanced): 1 x Captive Screw Connector, 3-pole Digital Audio: 1 x Coaxial Amplifier out: 1 x Captive Screw Connector, 4-pole |
Input | Stereo Audio (HDMI/HDBT): 1 x mini stereo Jack female (Green) Microphone: 1 x Captive Screw Connector, 3-pole (with selectable phantom power) |
Control | |
RS-232 | 1x DB-9 Female (Black); VP device control & configuration 1 x Captive Screw Connector, 3-pole ; AV device control |
IR | 1 x Mini Stereo Jack Female (Black); VP device control 1 x Captive Screw Connector, 2-pole; AV device control |
Ethernet | 1 x RJ-45 Female (Silver); Support PJLink protocol |
Interfaces | |
Relay | 2 x Captive Screw Connector, 2-pole |
Switches | |
Power | 1 x Pushbutton (LED: Green / Orange) 1 x Slide Switch (+48V Phantom Power) |
Video Input Port Selection | 5 x Pushbutton (LED: Green) |
Video Output Port Selection | 2 x Pushbutton (LED: Orange) |
Selection | Mic: 1 x Knob Volume: 1 x Knob Mode / Unlock: 1 x Pushbutton Function keys: 4x Pushbutton |
EDID Settings | EDID Mode: ATEN Default / Display A / Remix |
Connectors | |
Power | 1 x 3-Prong AC Socket |
Power Consumption | AC110V:46.7W:314BTU AC220V:45.8W:310BTU |
Environmental | |
Operating Temperature | 0-40°C |
Storage Temperature | -20 - 60°C |
Humidity | 0 - 80% RH, Non-Condensing |
Physical Properties | |
Housing | Metal |
Weight | 3.80 kg ( 8.37 lb ) |
Dimensions (L x W x H) | 43.24 x 27.23 x 4.40 cm (17.02 x 10.72 x 1.73 in.) |
Carton Lot | 3 pcs |
Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
Input Resolutions | 640 x 480 @ 60 / 67 / 72 / 75 Hz | 1600 x 1200 @ 60 Hz | 720p /1080i / 1080p / 50 Hz |
720 x 400 @ 70 Hz | 1680 x 1050 @ 60 Hz | 1080p 24 /25 / 30 Hz | |
800 x 600 @ 56 / 60 / 72 / 75 Hz | 1920 x 1080 @ 60 Hz | 1080p 120 / 240 Hz | |
1024 x 768 @ 60 / 70 / 75 Hz | 1920 x 1200 @ 60 Hz / 60 Hz (Reduced Blanking) |
3840 x 2160p 24 / 25 / 30 / 50 / 60 Hz | |
1280 x 800 @ 60 Hz | 1080p / 720p / 1080i 60 Hz | 4096 x 2160p 24 / 25 / 30 / 50 / 60 Hz | |
1280 x 1024 @ 60 / 75 Hz | 480p 60 Hz (4:3) / (16:9) | 3840 x 2160p 50 / 60 Hz 4:2:0 | |
1400 x 1050 @ 60 Hz | 640 x 480 60 Hz (4:3) | 4096 x 2160p 50 /60 Hz 4:2:0 | |
1440 x 900 @ 60 Hz | 576p 50 Hz (4:3) / (16:9) |
