CAT5 DVI KVM Extender Over LAN w/ Audio & Mic
KE861
KE861 the CAT5 DVI KVM Extender Over LAN w/ Audio & Mic.With these two units at hand, they are able to extend the distance between remote and local console up to 100 meters away via a CAT5 cable, including keyboard, monitor, mouse, speaker, microphone, and USB devices.
KE861 the CAT5 DVI KVM Extender Over LAN w/ Audio & Mic, consists of two individual untis: Transmitter (KE861-TX) and Receiver (KE861-RX). With these two units at hand, they are able to extend the distance between remote and local console up to 100 meters away via a CAT5 cable, including keyboard, monitor, mouse, speaker, microphone, and USB devices. KE861 utilizes new IP extender technology that user can not only deploy remote console in a more flexible manner, but also enjoy the high resolution rate of 1920 x 1080 @ 60 Hz / Full HD 1080p at the same time. It's an ideal solution for use in an exhibition room, worling floors, security room, locked server room, control center, or other mission-critical scenarios. Furthermore, KE861 support Graphic Mode & Video Mode selection to suit display requirements. Graphic mode is optimized for still graphic displays; while video mode is best for a dynamically changing video stream.
Features
- CAT5 DVI KVM Extender Over LAN
- Extension distance up to 100 m / 330 ft. over a single CAT5 UTP cable segment.
- Extending another 100 m by adding the Giagabit Ethernet Switch through CAT5 cable between Transmitter and Receiver Units.
- 4 x USB 2.0 ports with USB extension over IP for keyboard, mouse and other devices.
- Support Audio and Mic. extension over LAN
- Digital video resolution support up to 1920 x 1080 / Full HD 1080p up to 100 m
- Graphic Mode and Video Mode for selection
- Fully compatible with USB HID device for any keyboard, mouse and USB devices
- Supports multiplatform OS such as Windows 95 / 98 / 2000 / XP / Vista / 7 / Windows 8 and Linux
- Easy Plug-and-Play application, no configuration required
- Optional IR Remote Control Unit accessories available
Specification
| Model No. | KE861 |
| Product Description | CAT5 DVI KVM Extender Over LAN w/ Audio & Mic |
| Number of Console | 1 (Remote) |
| Maximum PC Connections | 1 (Local) |
| Console Keyboard Connector | (RX) USB Type A Female |
| Console Mouse Connector | (RX) USB Type A Female |
| Console Video Connector | (RX) DVI Female x 1 |
| Console Audio/Mic Connector | (RX) 3.5 mm Audio / Mic Jack Female x 2 |
| Console USB Hub Ports | (RX) USB Type A Female x 2 |
| PC Keyboard Connector | (TX) USB Type B Female |
| PC Mouse Connector | (TX) Via PC Keyboard Connector |
| PC Video Connector | (TX) DVI Female |
| PC Audio/Mic Connector | (TX) 2 x 3.5 mm Audio / Mic Jack Female |
| IR support | Yes (Optional) |
| TX Connectors | RJ45 Female |
| RX Connectors | RJ45 Female |
| Audio& Mic Extension | Yes |
| Cable media | CAT5 |
| Power LED | 2 (Red) |
| LED Status | 2 x Green (Link) |
| Digital Display Resolution | 1920 x 1080 |
| Keyboard & Mouse Emulation | Yes |
| OSD Menu | Yes |
| Operation Temperature | 0 ~ 40 °C |
| Storage Temperature | -20 ~ 60 °C |
| Humidity | 0 ~ 90 % RH, Non-Condensing |
| Power Adapter | DC 9V (on each unit) |
| Housing | Metal |
| Dimension(L×W×H) | 134 x 120 x 26 (mm) |
| Safety / Emission | FCC, CE |
