CE840
กรุณาสอบถามทาง Line @macrocare
สินค้ามีจำนวนจำกัด
Availability date:
100m True 4K HDMI/USB HDBaseT 3.0 KVM Extender (4K@100m)
ผู้รับ: :
* ฟิลด์ที่จำเป็น
หรือ ยกเลิก
Function | CE840L | CE840R |
Connectors | ||
Console Ports | 1 x HDMI (Female, Black) 4 x USB Type A (Female, White) * 1 x Mini Stereo Jack (Female, Green) 1 x Mini Stereo Jack (Female, Pink) * 2 ports x USB for Keyboard & Mouse use, 2 ports x USB for other USB2.0 peripherals, DO NOT mix and match |
1 x HDMI (Female, Black) 4 x USB Type A (Female, White) * 1 x Mini Stereo Jack (Female, Green) 1 x Mini Stereo Jack (Female, Pink) 1 x GbE (RJ-45 Female, Black) * 2 ports x USB for Keyboard & Mouse use, 2 ports x USB for other USB2.0 peripherals, DO NOT mix and match |
KVM Ports | 1 x HDMI (Female, Black) 1 x USB Type B (Female, White) 1 x Mini Stereo Jack (Female, Green) 1 x Mini Stereo Jack (Female, Pink) 1 x GbE (RJ-45 Female, Black) |
N/A |
RS-232 | 1 x DB-9 Female (Black) | 1 x DB-9 Male (Black) |
Power | 1 x DC Jack (Black) | 1 x DC Jack (Black) |
Unit To Unit | 1 x RJ-45 Female (Black, HDBaseT) | 1 x RJ-45 Female (Black, HDBaseT) |
Video | ||
Max. Data Rate | 18Gbps (6Gbps per lane) | 18Gbps (6Gbps per lane) |
Max. Pixel Clock | 600 MHz | 600 MHz |
Compliance | HDMI (Deep Color, 4K/60Hz); 4K HDR+ HDCP2.3 Compatible Consumer Electronics Control (CEC)* *The CEC signals are only bypassed from the Local unit to the remote unit and do not support local HDMI console output. |
HDMI (Deep Color, 4K/60Hz); 4K HDR+ HDCP2.3 Compatible Consumer Electronics Control (CEC) |
Max. Resolution | 4096 x 2160 @ 60Hz (4:4:4) 3840 x 2160 @ 60Hz (4:4:4) |
4096 x 2160 @ 60Hz (4:4:4) 3840 x 2160 @ 60Hz (4:4:4) |
Max. Resolutions / Distance | 4K x 2K @ 60Hz (4:4:4) up to 100m (HDBaseT3 Certified Cat 6a U/FTP cable or above / ATEN 2L-2920 Cat 6a cable) 4K x 2K @ 30Hz (4:4:4) up to 50m (HDBaseT certified Cat6 cable / ATEN 2L-2910 cable) |
4K x 2K @ 60Hz (4:4:4) up to 100m (HDBaseT3 Certified Cat 6a U/FTP cable or above / ATEN 2L-2920 Cat 6a cable) 4K x 2K @ 30Hz (4:4:4) up to 50m (HDBaseT certified Cat6 cable / ATEN 2L-2910 cable) |
LEDs | ||
Power | 1 (Green) | 1 (Green) |
Link | 1 (Orange) | 1 (Orange) |
Video | 1 x HDMI IN (Orange) | 1 x HDMI OUT (Orange) |
Console Status | 3 x Local USB Keyboard/Mouse Authority Indicator (Green) | 3 x Remote USB Keyboard/Mouse Authority Indicator (Green) |
Switches | ||
Long Reach Mode Switch | 1 x Slide Switch (Reserved) | 1 x Slide Switch (Reserved) |
Firmware Upgrade | 1 x Slide Switch | 1 x Slide Switch |
Pushbuttons | ||
Wakeup button | N/A | 1 x Pushbutton |
Operating Mode Selection | 1 x Local USB Keyboard/Mouse Authority switch | 1 x Remote USB Keyboard/Mouse Authority switch |
Power Consumption | DC12V:7.36W:60BTU | DC12V:7.37W:60BTU |
Environmental | ||
Operating Temperature | 0-40˚C | 0-40˚C |
Storage Temperature | -20-60˚C | -20-60˚C |
Humidity | 0-80% RH, Non-condensing | 0-80% RH, Non-condensing |
Physical Properties | ||
Housing | Metal | Metal |
Weight | 0.82 kg ( 1.81 lb ) | 0.81 kg ( 1.78 lb ) |
Dimensions (L x W x H) | 17.82 x 15.60 x 2.88 cm (7.02 x 6.14 x 1.13 in.) |
17.82 x 15.60 x 2.88 cm (7.02 x 6.14 x 1.13 in.) |
Note | Long reach mode reserved for future improvement | Long reach mode reserved for future improvement |
Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
Input Resolutions | 640 x 480 @ 60/67/72/75 Hz | 720p 60 Hz |
800 x 600 @ 56/60/72/75 Hz | 1080i 60 Hz | |
1024 x 768 @ 60/70/75 Hz | 640 x 480 60Hz (4:3) | |
1280 x 800 @ 60 Hz | 576p 50 Hz (4:3)/(16:9) | |
1280 x 1024 @ 60/75 Hz | 720p 50 Hz | |
1400 x 1050 @ 60 Hz | 1080i 50 Hz | |
1440 x 900 @ 60 Hz | 1080p 24/25/30/50 Hz | |
1600 x 1200 @ 60 Hz | 3840 x 2160p 24/25/30/50/60 Hz | |
1680 x 1050 @ 60 Hz | 4096 x 2160p 24/25/30/50/60 Hz | |
1920 x 1080 @ 60/120 Hz | 3840 x 2160p 50 Hz 4:2:0/60 Hz 4:2:0 | |
1920 x 1200 @ 60 Hz | 4096 x 2160p 50 Hz 4:2:0/60 Hz 4:2:0 | |
1920 x 1200 @ 60 Hz (Reduced Blanking) | 1920 x 1080 @ 144 Hz | |
1080p 60 Hz | 2560 x 1440 @ 144 Hz | |
480p 60 Hz (4:3) / (16:9) |
