MR108
8-Port USB/PS2 KVM Switch with IP Solot for IP Card installation (option), including 1.8m KVM cables
กรุณาสอบถามทาง Line @macrocare
สินค้ามีจำนวนจำกัด
Availability date:
Rack-Mountable KVM Switch, VGA 8ports
8-Port USB/PS2 KVM Switch with IP Solot for IP Card installation (option), including 1.8m KVM cables
ผู้รับ: :
* ฟิลด์ที่จำเป็น
หรือ ยกเลิก
The MR108, USB / PS/2 KVM (Keyboard, Video, Mouse) Switches are control units that allow access and control of up to 8 computers from a single USB / PS/2 keyboard, USB / PS/2 mouse, and monitor console.
Function | 8 port | ||
Computer Connections | Direct |
8 | |
Cascade(Max) |
128 | ||
CPU Port Selection | OSD Menu, Front Panel, Hot-Key, | ||
Connector | Console Connectors |
Video | 1 x VGA DB15 Female Blue |
Keyboard | 1 x USB Type A Female, 1 x PS2 Female (Purple) | ||
Mouse | 1 x USB Type A Female, 1 x PS2 Female (Green) | ||
Computer Connectors | Video/Keyboard/Mouse | 8 x VGA DB15 Female (Blue) | |
Power |
1 x DC | ||
Key Switch | Connection Port Selection | 8 x Button | |
KVM Reset | 1 x Semi-embedded keys | ||
IP Module Reset | 1 x Semi-embedded keys | ||
IP Module Default | 1 x Semi-embedded keys | ||
LEDs | Computer Selection Port | 8 x Green | |
On Line | 8 x Red | ||
Analog Mode | Keyboard, Mouse | USB, PS2 | |
Video resolution (Max) | 1920 x 1200 @ 60HZ Local | ||
Scan time interval | 3, 5, 10, 15, 20, 30, 40, 60s (3s by default) | ||
Operating Environment | Operating temperature | -10˚C~50˚C | |
Storage temperature | -20˚C~60˚C | ||
Humidity | 0-80%RH, No Condensation | ||
Physical Properties | Housing | Metal | |
Size | 432 x 155 x 44 mm | ||
Weight | 1.82KG |
