PTZ312
กรุณาสอบถามทาง Line @macrocare
สินค้ามีจำนวนจำกัด
Availability date:
12x Optical Zoom PTZ Video Conference Camera with HDMI, USB2.0, LAN
ผู้รับ: :
* ฟิลด์ที่จำเป็น
หรือ ยกเลิก
Camera CMS software for Windows
หมายเหตุ ไม่รองรับการใช้งานร่วมกับ Line บน PC
Technical Data | |
Model | PTZ312 |
Image Sensor | 1/2.8" CMOS, 2.14 MP |
Lens | f=3.9~46.8mm, F1.6~F2.8 |
Digital Zoom | 8X |
Field Of View | 72.5° - 6.3° |
Focus | Auto/Manual/PTZ Trigger/One Push Trigger |
Min. Illumination | 0.5Lux |
Shutter Speed | 1/60s~1/10,000s |
Gain | Auto/Manual |
White Balance | Auto/One Push/Manual/Static |
AE Control | Auto/Manual/Shutter Priority/Iris Priority/Bright Priority |
S/N | ≥50dB |
DNR | 2D/3D |
BLC | Support |
PTZ | |
Pan Angle | -170°~+170°;0.1°~120°/s |
Tilt Angle | -30°~+90°;0.1°~80°/s |
Preset Number | 256 |
Menu | Support |
Image Flip | Support |
Interface | |
HDMI | 1 channel HDMI |
Network | RJ45(10M/100M) |
1.Up to 1080P30 | |
2.Image compression H.264/H.265 | |
3.Support HTTP/TCP/UDP/RTSP/RTMP/ONVIF | |
4.Support AAC | |
5.Support dual streaming | |
USB | 1 channel USB 2.0 |
Audio Interface | 1 channel LINE IN |
Control Interface | 1 channel RS-232 IN, 1 channel RS-232 OUT |
Power | DC12V |
General | |
Protocols | VISCA (support daisy chain)/PELCO-P/PELCO-D |
Addresses | DC12V |
Power Consumption | <18W |
Working Environment | Temperature:0°C ~ + 40°C;Relative Humidity:10%RH ~ 90%RH |
Storage Environment | Temperature:-20°C ~ +60°C;Relative Humidity:10%RH ~ 95%RH |
Dimensions | 243mm×145mm×163mm(W*D*H) |
Weight | 1.2kg |
Color | Grey |
