KVM Switch 16-Port Rackmountable USB-PS/2 KVM Switch w/ OSD, Daisy-Chainable
KV8116
สลับใช้งานคอมพิวเตอร์ 16 เครื่องภายในตู้ Rack ด้วย จอ VGA, คีย์บอร์ด,เมาส์ PS/2 และ USB ชุดเดียวกัน, สลับสัญญาณด้วย OSD Menu, ต่อพ่วงแบบ Cascadable ได้ 8 ระดับ, มีระบบรหัสผ่านในการใช้งาน
KV8116 is a 16-port USB PS/2 Rackmount KVM Switch that is designed for computer/server management on a central console in corporate, factory as well as in campus computing environment. It provides the OSD Menu for intuitive KVM switching operations. Its cascadable feature can help upscale the server number to hundreds. The KVM switches offer a dedicated controller per port to keep the mouse and keyboard alive even when the KVM switch is not powered on. Excellent video quality with minimal degradation is guaranteed even when daisy-chained up to 8 units. Perfect keyboard/mouse emulation provides high compatibility with machines and operating systems.
Feature
- 16-port 19” Cascadable Rackmount USB PS/2 KVM switch with OSD
- Cascadable up to 8 units using daisy-chain cable
- Daisy-chaining distance up to a total of 30 M
- Port capacity scalable up to 128 PCs
- USB and PS/2 interface support on both console and PC side
- Support Microsoft and Logitech standard 5-key mouse and compatibles
- Computer selection and operation using front-panel push buttons , keyboard hotkeys and OSD Menu
- Support for DOS, Windows 95/98/SE/ME/2000/XP, Linux, MacOS, etc.
- Numerical LED display and LED indicators for easy bank/port status monitoring
- Perfect keyboard/mouse emulation to ensure compatibility t to all machines and operating systems
- One controller per to keep alive even when the KVM is not powered on
- Enhanced PS/2 mouse reset hotkeys for non-PnP OS such as Win NT 4.0 and Linux
- Plug-and-Play for PnP OS, no Windows driver software needed
- Buzzer sound for hotkey and port switching confirmation
- Autoscan period programmable 5 ~ 95 through OSD Menu option
- Password protection
- Auto-logout timeout support
- High VGA resolution 2048 x 1536
- Firmware upgradable
Specifications
| Model No. | KV8116 |
| Product Description | 16-Port Rackmountable USB-PS/2 KVM Switch w/ OSD, Daisy-Chainable |
| Number of Ports | 16 |
| Number of Console | 1 |
| Maximum PC Connections | 256 |
| Console Keyboard Connector | PS/2 Female + USB Type A Female |
| Console Mouse Connector | PS/2 Female + USB Type A Female |
| Console Video Connector | VGA HDB15 Female |
| PC Keyboard Connector | Via Video Connector |
| PC Mouse Connector | Via Video Connector |
| PC Video Connector | 16 x VGA HDB15 Female |
| Chain Topology | Daisy-Chain |
| Daisy-chain port Connector | HDB15 Female HDB15 Male |
| Chain Levels | 16 |
| PC selection | Push Button / Hotkeys / OSD |
| PC port LED | 16 (Green) 16 (Red) |
| Analog Display Resolution | 2048 x 1536 |
| Keyboard & Mouse Emulation | Yes |
| OSD Menu | Yes |
| Auto Scan Delay Time | 5~99 sec |
| Operation Temperature | 0 ~ 40°C |
| Storage Temperature | -20 ~ 60°C |
| Humidity | 0~90% RH, Non-Condensing |
| Power type | PS/2 + USB Bus Power |
| Power Adapter | DC 9V/1A |
| Weight | 2Kg |
| Dimension(L×W×H) | 408.5 x 164 x 45mm |
| Safety / Emission | FCC, CE |
| Cable Part No. | CAB-2067 |
